Emtek Outback Series Mortise Entry Door Lock Set

$1,583.00

The Emtek Outback Series Mortise Entry Door Lock Set offers a sleek and contemporary design with the slender 1 ¾" wide trim available in both the monolithic Brisbane and full-length Adelaide styles. Enjoy the perfect blend of style, security, and performance with this elegant lock set.

This product ships within 7 days.

Emtek’s Outback Series Mortise Entry Door Lock Set features the chic and modern Brisbane and Adelaide designs, for a clean and contemporary silhouette. Both the monolithic Brisbane and full-length Adelaide sets offer a slender 1 ¾" wide trim that enhances the visual appeal of any door.

A mortise lock set is a high-security locking mechanism that is installed into a mortise cut into the edge of the door. This type of lock is an excellent choice for front doors where security is paramount. The Outback Series combines the elegant design of Emtek’s entry sets with the robust security of a mortise lock, providing both style and peace of mind for your home.

Functions

F13 Mortise

Operates as a standard keyed lock
Key outside operates both bolts
Inside lever retracts latch and deadbolt simultaneously
UL180 minute fire rating
Heavy duty lock body
Forged deadbolt latch with Anti-Saw inserts
Anti-Friction latch trigger
Deadlocking latch bolt

F20 Mortise

Key outside operates both bolts
Inside lever retracts latch and deadbolt simultaneously
Always locked from the outside
- Includes a mechanism to temporarily override the outside lock
- Activated by pressing the release button on the latch plate
- To cancel, use the stop button or project the deadboltUL180 minute fire rating
Heavy duty lock body
Forged deadbolt latch with Anti-Saw inserts
Anti-Friction latch trigger
Deadlocking latch bolt

Technical Specifications & Installation Guides

Mortise-Entry-Sets_EM_Instructions.pdf



EMTEK Cylinder, Face Plate, Strike Plate, Understrike Plate and Dust Box Dimensions

EMTEK Active Mortise Lock Hole Preparation (Left Hand)

UL Grip by Lever, Grip by Knob Active Mortise Lock Technical Specifications (Right Hand)

EMTEK Dummy Mortise Lock Door Prep - Right Hand

Mortise-Entry-Sets_EM_Specs.pdf

EMTEK Dimensions-Door Thickness Specifications for Mortise Locksets

EMTEK Dummy Mortise Lock Door Prep - Left Hand

EMTEK Dummy Mortise Lock Installation Instructions

EMTEK Dummy Mortise Lock Installation Instructions - Trilingual

EMTEK UL Mortise Lock Installation Guide - F13 Function

EMTEK UL Mortise Lock Installation Guide - F20 Function

Emtek Mortise Lock Functions
