Top-Mounted Spoke Wheel Barn Door Hardware

Details Features Overview FAQ Reviews Guides Variants Craftsmanship
Skip to product information
Top-Mounted Spoke Wheel Barn Door Hardware
  • Top-Mounted Spoke Wheel Barn Door Hardware
  • Top-Mounted Spoke Wheel Barn Door Hardware
  • Top-Mounted Spoke Wheel Barn Door Hardware
Top-Mounted Spoke Wheel Barn Door Hardware

Top-Mounted Spoke Wheel Barn Door Hardware

Ships same day or next day

Top-mounted spoke wheel barn door hardware that combines rustic charm with industrial strength. Features large black polymer wheels with 5 spokes per wheel, styled after traditional barn sliding systems. Hangers mount to the top of the door for a clean, uncluttered face—perfect for showcasing your door's design. The smooth-rolling wheels are built from durable polymer, while the rest of the kit is available in Black or Dark Bronze finishes.

This hardware works beautifully with weathered barn doors for vintage appeal, or pair it with horizontal plank doors in exotic woods for a modern aesthetic. Reclaimed wood doors and doors with X or Z braces are especially striking with this system. At 150lb weight rating per pair of hangers, it's one of our strongest flat track options, delivering both style and reliable performance for any sliding door application.

Note: For the complete kit, be sure to complete Step 1 and Step 2, adding both items to your cart.

Step One

Flat Track

Flat Track

Required

Select a track length at least twice the width of your door.

For bi-parting applications, track length should be twice the width of both doors combined.

Have questions? Need a custom track length, finish, or header board? Call us at (253)-853-3815.

Step Two

Spoke Wheel Hangers

*Maximum of 2.

Spoke Wheel Hangers

Required

Note:
1/2" Standoff Rings are REQUIRED if the mounted doors are 2-1/4" or thicker.

Full Polymer Hush Wheels:
The entire wheel is made of black polymer "hush" material so it will glide along the track quietly.

Steel Matched Wheels:
For the most cohesive aesthetic, these wheels match the finish color selected.

Steel Matched Wheels with Hush Insert:
Wheels are made of solid steel with a powder-coated finish with a black polymer insert where it makes contact with the track. This helps the wheels glide along the track more quietly.

How Many Doors?

*Maximum of 2.

Recommended Accessories
Easy Mount Header Board

Removes the need for wood blocking in the wall.
Easy Mount Header Board

All Headers are 5.5" tall and made with Paint Grade Solid Wood. Headers add 1.5" on each side to better fit the hardware track.

Easy Mount Header Board

Quantity*

All Headers are 5.5" tall and made with Paint Grade Solid Wood. Headers add 1.5" on each side to better fit the hardware track.
Track Accessories
End Stop, Adjustable for Flat Track Kits

*1 Per Door Slab

End Stop, Adjustable for Flat Track Kits

Quantity*

*1 Per Door Slab
Floor Guides
C-Guide Sliding Barn Door Floor Guide Adjustable Width

*1 Per Door Slab

C-Guide Sliding Barn Door Floor Guide Adjustable Width

Quantity*

*1 Per Door Slab
Handles + Pulls
Stand Off + Mounting Rings

Your Hardware Kit

Required

Accessories

Add a Step One and Step Two product above to start your kit.

Subtotal

Please add Step One and Step Two before checkout.

CHECKOUT

Product Information
  • Application: Interior
  • Hardware Material: Powder-coated Black or Dark Bronze
  • Track System: Single or Bi-Parting
  • Weight Capacity (per pair of hangers): 150 lbs
  • Soft Stop Compatibility: Compatible
  • Mounting: Wall/Side Mounted
  • Country of Origin: United States (Gig Harbor, WA)
What's In the Kit?
  • Solid steel rail (May ship in pieces depending on selection)
  • 2x hangers with wheels per each door on the track
  • All required nuts and bolts
  • Anti-jump plate
  • T-Guide for guiding your door
  • Standoffs
  • 2x 1/2" spacer guide for installing hangers to door
  • 2x stationary end stops for each set of 2 hangers

Please note that doors are not included with the purchase of hardware.
Sizing Guide

Sizing For A Single Barn Door

Multiply your door width by two to get the correct track length.

Example: For a 3' wide barn door, you'd need a 6' barn door hardware kit.

Sizing For Bi-Parting Barn Doors

You'll need to add the door widths together and then multiply that sum by two.

Example: For two 3' wide bi-parting doors, you'll need a 12' track. When you make your selections in the menu, change the quantity of doors on track to the correct amount. That way we can send you all the hangers and additions you'll need.

If your door requires a track length that falls between sizes, you can round up to the next size and add the adjustable end stop. This will allow you to choose where the doors tops on the track. We are also able to cut tracks to your specifications.

For custom track lengths, call us at (253) 853-3815

For more details, see How to Measure For a Barn Door - An Illustrated Guide.
Accessory Information
  • Soft Stop: Keeps the door from slamming. Closing will be smooth and soft.

  • Adjustable End Stop: Choose exactly where you want your door to stop on the track. This is an optimal way to create space for light switches.

    Note: Soft stops and adjustable end stops are not compatible with each other.

  • Wall Mounted Roller Guide: Heavy-duty, reliable, and optimal for thicker doors or in rooms where you can't drill into the floor.

  • C-Guide: A sleek and elegant floor guide. If you have to see it all the time, it might as well be beautiful.

  • Standoff Rings: Make room for wall molding so the door has optimal clearance.

  • Drywall Anti-Crushing Rings: Keep the track hanging straight instead of leaning away from the wall over time.
Shipping Protection

We've partnered with UPS Capital to introduce an advanced shipping protection plan. This plan shields your purchases against any unforeseen events during transit. Guard your package against loss, theft, or damage. Visit our Shipping Protection page to learn more.
Technical Guides

Still have questions? Click the chatbox on the bottom right to speak with a sales associate, or call us at (253) 853-3815.
